Video-Wall Matrix Processor 2E VWPR3x3MX HDMI 3×3 4K 2K 60Hz 4:4:4
Video-Wall Matrix Processor 2E VWPR3x3MX HDMI 3×3 4K 2K 60Hz 4:4:4
Video-Wall Matrix Processor 2E VWPR3x3MX HDMI 3×3 4K 2K 60Hz 4:4:4

Video-Wall Matrix Processor 2E VWPR3x3MX HDMI 3×3 4K 2K 60Hz 4:4:4

Product code: VWPR3X3MX

The 2E video wall processor is designed to broadcast a single HDMI signal to nine displays in a 3 × 3 configuration, forming a seamless image for large-format installations. It features high-quality signal scaling, intuitive control, and adjustable bezel compensation, ensuring accurate content display across the entire video wall surface. The solution is optimized for creating a single visual canvas from multiple LCD displays. This approach enables the effective implementation of digital signage, information panels, and demonstration areas with large-scale content display. It is possible to combine 4, 6, 8, or 9 displays in 2 × 2, 2 × 3, 2 × 4, or 3 × 3 configurations, which expands the system’s adaptability to the specific characteristics of the space and the task at hand. Control is implemented in several ways: via front-panel buttons, an infrared (IR) remote control, or an RS232 serial interface, simplifying integration into professional AV systems.

  • One HDMI input up to 4K/30 Hz
  • Nine HDMI outputs with 1080p/60 Hz resolution
  • Display modes: 2 × 2, 2 × 3, 2 × 4, 3 × 3
  • On-Screen Display (OSD) for mode and port information
  • Power-off memory function
  • Independent 180° image rotation for each HDMI output (modes 1–12)
  • Bezel compensation
  • Edge Masking with 8-pixel increments (max. edge correction 8×20 pixels)
  • Support for LPCM, AC3, and DTS digital audio formats
  • Control: buttons on the unit, IR remote, RS232
139.99 €*
Main:
Type процесор відеостіни
Signal transmission HDMI
Device compatibility screens / video walls / з підтримкою HDMI дев’ять виходів із фіксованою роздільною здатністю 1080p@60Hz
Output signal resolution 1080p@60Hz
Inputs HDMI
Outputs 9 x HDMI
Warranty:
Warranty 12 months
High-resolution photo Data Sheet

Scaling and Image Integrity

Thanks to built-in signal scaling algorithms, content is correctly distributed across all screens without loss of aspect ratio or sharpness. Support for input resolutions up to 4K allows for high-quality content, while the 1080p/60 Hz output resolution guarantees stable display on every screen.

Video Wall Configuration Flexibility

Support is provided for multiple screen layout modes—2 × 2, 2 × 3, 2 × 4, and 3 × 3. This allows the system to be adapted to specific tasks and the available number of displays. This approach ensures flexibility when deploying both compact and large-scale video walls.

Precise Adjustment and Bezel Compensation

The bezel compensation feature allows you to align images while accounting for the physical boundaries of the displays, creating a seamless visual canvas. Additionally, Edge Masking is provided, which helps adjust image borders in 8-pixel increments, achieving the most natural-looking content.

Orientation and Visual Presentation Control

Each HDMI output supports independent 180° image rotation, expanding display installation options and optimizing the system for various spatial conditions. This is particularly relevant for non-standard installations.

Intuitive control and integration

The processor can be controlled in several ways: via front-panel buttons, an infrared remote control, or the RS232 interface. The on-screen display (OSD) simplifies configuration and monitoring of operating parameters. The power-off memory function ensures quick system recovery without the need for reconfiguration.

Audio and Comprehensive Signal Transmission

The device supports LPCM, AC3, and DTS digital audio formats, ensuring synchronized audio transmission with video. This allows the system to be used not only for visual content but also for multimedia presentations.
