2E DD2000 UPS, 2000VA/1200W, LCD, USB, 2xSchuko 2E-DD2000
As a result of shelling of power system facilities in various cities in Ukraine, fan and emergency power outages have been introduced. Therefore, at any moment, it is possible to stop the power supply and, as a result, turn off important equipment, which can lead to its damage or even complete failure. 2E brand uninterruptible power supply (UPS) will save in these cases.
| Device type | line-interactive |
| View | Computer and household UPS |
| Mounting type | classic (tower) |
| Input voltage | 162-295 V |
| Input frequency | 50-60 |
| Output voltage | 220 V / 230 V / 240 V |
| Max. Output Power | 2000 VA |
| Effective Output Power | 1200 W |
| Output frequency | 50-60 |
| Outlets with a reserve | 2 pcs SCHUKO |
| Type of output power | SCHUKO |
| Established batteries | 2 pcs 12В / 9 Aг |
| Interface | USB |
| Additional information | "restart" function / automatic voltage regulation AVR / cold start function |
| Display | ✔️ (LCD з інформацією про стан ДБЖ) |
| Noise level | 45 dB (1 м) |
| Operating temperature | 0-40 °C |
| Relative humidity | 20 - 90% |
| Colour | black |
| Dimensions ( HxWxD ) | 225x125x380 |
| Battery warranty | 1 year (2 роки на електроніку) |
| The weight | 12.9 kg |
In the event of a power outage or other problems with the network, the output sockets continue to receive voltage from the UPS for a limited time. Connect critical equipment, such as a computer, monitor or other data transmission devices, to the output sockets.
Do not connect non-computer related equipment to the UPS, such as medical equipment, life support equipment, microwave ovens and vacuum cleaners.
An input fuse/circuit breaker provides protection against unstable input current.
2E-DD2000 UPS linear-interactive type with a capacity of 2,000 VA/1,200 W. Input: 162-295 VAC. Output: 220/230/240 V ± 10%. The frequency is 50/60 Hz ± 1% (automatic detection). Automatic test at power-on. AVR automatic voltage stabilization. There are two Schuko sockets with battery power.
Cold start and restart functions, protection against short circuit, overload and surges. Charging the battery in the off state. Intelligent battery management: battery temperature compensation to extend battery life; three-stage charging to reduce charging time. Information about the UPS operation status is displayed on the LCD. Interface: USB. Two built-in batteries of 12 V/9 Ah. Size (W × D × H): 125 × 380 × 225 mm. Weight: 12.9 kg. Noise level: 45 dB (1 m).
This UPS is intended for indoor use only, in a closed, controlled environment.
