4K Ultra HD with Sony CMOS Sensor
The PTZ camera is equipped with an 8.29-megapixel 1/2.8″ Sony CMOS sensor that provides 4K Ultra HD video (3,840 × 2,160) at up to 30 fps. Thanks to an advanced image processing system, the system delivers clear, detailed video with natural color reproduction, which is especially important for business meetings, presentations, and educational events. Autofocus, automatic and manual exposure adjustment, and 2D/3D Noise Reduction ensure consistently high image quality even in challenging lighting conditions.
12x Optical Zoom and PTZ Control
The camera features 12x optical zoom, allowing the image to be magnified without loss of detail. The lens with a focal length of 3.9–46.8 mm and an aperture of F1.8–F2.8 provides high-quality images both in wide room views and when displaying the presenter in close-up. The PTZ mechanism supports: ±175° pan; ±90° vertical rotation; pan speed of 0.1–80°/s; tilt speed of 0.1–60°/s. Up to 255 presets can be saved (10 via the remote control) for quick switching between predefined viewing angles.
High-Quality Audio for Team Collaboration
The package includes a professional speakerphone with eight built-in microphones that provide 360° voice pickup and effective operation in meeting rooms. The pickup range is up to 6 m and can be extended to 9 m by connecting two additional microphones, making the system suitable for spacious conference rooms. For improved communication quality, the system features AEC (Acoustic Echo Cancellation), effective noise reduction, and a signal-to-noise ratio of 62 dB. The built-in 5 W speaker with a maximum volume of 110 dB and a frequency range of 100 Hz–20 kHz provides clear and natural voice reproduction.
Flexible Connectivity Options
The system can be easily integrated into modern meeting rooms thanks to a wide range of interfaces: HDMI; USB Type-C; USB; DP for connecting the camera, speakerphone, and additional microphones. Control interfaces include RS-232, RS-485, VISCA, Pelco-D, and Pelco-P, enabling integration with professional automation systems. With Plug & Play support, the system is ready to operate almost immediately after connection.
Wide Compatibility with Modern Platforms
The 2E-VCS-4KZM supports Windows, macOS, Linux (UVC), and Android operating systems. The system is compatible with popular video conferencing platforms, including Microsoft Teams, Zoom, Skype, Google Meet, Cisco Webex, and other solutions supporting the UVC standard.
Comprehensive Solution for Professional Meeting Rooms
The set combines a professional PTZ camera, high-quality audio system, and switching hub in one integrated solution, significantly simplifying the setup of meeting rooms. The system is an effective solution for corporate conferences, online presentations, remote learning, and other scenarios where image quality, natural sound, and reliable operation are important.
