Product code: 2E-SD10000

In view of the military present, the source of uninterrupted power supply of 2E brand is a must-have for business and the stable functioning of critical public institutions, in particular, maternity hospitals, laboratories, etc. The model has a power of 10 kW. 2E SD10000 type: online double conversion. UPS of this class provide the most reliable protection of the connected equipment against interruptions in the power grid, which undoubtedly compensates for the costs of its purchase and installation.

69 036 uah.*
User manual Software High-resolution photo
Main:
Device type online with double conversion
View Server and network equipment UPS
Mounting type classic (tower)
Typical recharge time (up to 90%) 9 h
THDi ≤ 5%
SPS ≤ 1% linear load / ≤ 4% non-linear load
Overload 105% - 110% for 10 min / 110% - 125% for 1 min / > 126% - 150% for 30 s
Input:
Input Single-phase three-wire (1F + N + PE)
Input voltage range 110-176 V лінійне зниження характеристик між 50% та 100% навантаження / 176-288 V без погіршення характеристик
Input frequency 40-70 автоматичне визначення
Peak current 1 A
Output:
Output Single-phase three-wire (1F + N + PE)
Output voltage 220 V / 230 V / 240 V / 208 V
Max. Output Power 10000 VA
Effective Output Power 10000 W
Output frequency 50-60 ± 0,1% Гц у режимі роботи від батареї
Maximum efficiency ≥ 95% (60% load) / ≥ 94% (100% load) / ≥ 98% (ECO mode)
Type of output power Terminal block
Battery:
Established batteries 16 pcs x 12B 9 Aг
Connecting an external battery ✔️ 16 шт x 12B 9 Aг (опціонально)
Protection:
Protection Short circuit protection / Overload protection / overvoltage protection / discharge/overcharge protection перевірки вентилятора / IP 20
Additional information:
Interface USB / RS-232 / optional SNMP adapter
Additional information microprocessor control / ECO mode
Physical:
Display ✔️ LCD
Noise level 58 dB
Operating temperature 0-40 °C
Relative humidity 0-95% (non-condensing)
Colour black
Dimensions ( HxWxD ) 711 x 191 х 495
Battery warranty 1 year (2 роки на електроніку)
The weight 62 kg

The operation principle is that the input AC voltage is converted by the rectifier into DC, and then by the inverter – back into AC. Even in the presence of large deviations in the input voltage, 2E UPS continues to supply the connected devices with a pure sinusoidal stabilized voltage. The lack of switching between modes (mains to battery) allows to minimize the risk of damage to «sensitive» equipment. In particular, such UPSs are used for uninterrupted power supply of medical equipment, for data centers and enterprises with a continuous production cycle. The input voltage range is: 110 ~ 176 VAC (linear derating between 50% and 100% load); 176 ~ 288 VAC (no degradation). Input: single-phase three-wire (1F + N + PE). Output: single-phase three-wire (1F + N + PE), in addition, it is possible to adjust the voltage 208/220/230/240 V.

The operating frequency range of 2E SD10000 model is within 40 ~ 70 Hz (automatic detection). The UPS is equipped with sixteen batteries (12 Bt/9 Ah), which restore the charge to 90% in just 9 hours! The charging current (max.) is 1 A. In addition, various RS-232, USB and an optional SNMP adapter are provided. A multi-function LCD display built into the front panel displays the device’s operating status, including error codes.

With a weight of 62 kg, the device has dimensions of 191 × 495 × 711 mm. Installation type: TOWER. The noise level is 58 dB. The product has IP20 protection degree, as well as protection against short circuit, overload, overheating, full battery discharge and fan check ability.
